As the voltage is.

Step voltage test electric motors.

This article describes how the machine s insulation is tested and the information. When a motor fails it is often difficult to see why it failed just by looking at it. Step voltage test has become an industrial standard in common use for field testing. The leakage current is.

Ieee 43 2000 ieee 95 2002. Therefore if we use dc test voltage we ensure that the dc test voltage is under root 2 or 1 414 times the ac test voltage so the value of the dc voltage is equal to the ac voltage peaks. The first ones ieee 62 1958 eda test basis to the late ones. Minimum test value of the electric motor is 1 meg ohm 1 mω.

The dc voltage is applied to all three phases of the winding and raised slowly to a preprogrammed voltage step level and held for a predetermined time period. The standard procedure is to increase voltage in one minute increments. You should make these periodic tests in the same way each time. That is with the same test connections and with the same test voltage applied for the same length of time.

A quick check out can be done with. The step voltage test is performed upon completi on of a successful polarization index pi test starting at the same voltage used for the pi test. Dc step voltage test it is typically performed at twice line voltage plus 1000 volts. With the motor running check the running amps of the motor using clamp on meter.

Experience is the best teacher in setting up the scheduled periods for your equipment. How to check an electric motor. But smart companies understands is that what this means for maintenance programs is billions of dollars of lost revenue through increased motor repair costs downtime and waste in industrial and commercial companies. Match up to the full load.

Pump motor or a short control cable may be vital to a process in your plant. The test voltages governed by ieee are reflected in table ii. In this test there is a sudden breakdown of the insulation between about 5 6 and 6 5kv and the test is shut down at the end of step 7 at about 6500v because the acceleration in the measured current exceeded the roc limit from step 6 to step 7. For example for a 1500 v ac voltage the equivalent dc voltage to produce the same amount of stress on the insulation would be 1500 x 1 414 or 2121 v dc.

Step voltage test the step voltage test records the peak in rush and decay of current as each increase step in dc voltage is applied to the circuit. The voltage is increased in a series of steps and the leakage current is plotted. The test allows the technician to observe how the insulation system responds to an over voltage stress. Electric motor testing is usuallly the first thing to be sacrificed when cutting back on operational expenses.

Step voltage test this dc test is performed to a voltage that a motor typically sees during starting and stopping. 4160v motor test voltage 9320v.
